Running virtual machines (VMs) on an Ubuntu server can seem daunting, but it's actually quite straightforward once you get the hang of it. This guide will walk you through the process, step by step, ensuring you can efficiently manage and utilize VMs on your Ubuntu server.

Why Run VMs on Ubuntu Server?

Before diving into the how-to, let's quickly cover why you might want to run VMs on your Ubuntu server in the first place. There are several compelling reasons:

• Resource Optimization: VMs allow you to maximize the use of your server's resources. Instead of dedicating an entire physical server to a single application, you can run multiple VMs, each hosting different applications, on the same hardware. This leads to better resource utilization and cost savings.
• Isolation: VMs provide isolation between different applications and services. If one VM crashes or becomes infected with malware, it won't affect the other VMs on the same server. This isolation enhances security and stability.
• Flexibility and Scalability: VMs make it easy to deploy and manage different operating systems and applications. You can quickly create new VMs to meet changing demands and scale your infrastructure as needed.
• Testing and Development: VMs are ideal for testing new software and configurations without affecting your production environment. You can easily create and destroy VMs for testing purposes, ensuring a safe and isolated environment.
• Disaster Recovery: VMs can be easily backed up and restored, making them an essential part of your disaster recovery strategy. In the event of a server failure, you can quickly restore your VMs to a new server and minimize downtime.

Prerequisites

Before we start, make sure you have the following:

• An Ubuntu server: You'll need a server running Ubuntu. It's best to have a fresh installation to avoid conflicts.
• Sufficient resources: Ensure your server has enough RAM, CPU, and storage to run the VMs you plan to create. A general guideline is to have at least 8GB of RAM and a multi-core processor.
• Root access: You'll need root or sudo privileges to install and configure the necessary software.
• Internet connection: An active internet connection is required to download packages and updates.

Step 1: Install KVM and QEMU

KVM (Kernel-based Virtual Machine) is a virtualization module in the Linux kernel that allows you to run VMs. QEMU (Quick Emulator) is a generic and open-source machine emulator and virtualizer. Together, they provide the foundation for running VMs on your Ubuntu server. To install KVM and QEMU, follow these steps:

1. Open a terminal on your Ubuntu server.

2. Update the package list:

   sudo apt update


3. Install KVM and QEMU along with the necessary utilities:

   sudo apt install qemu-kvm libvirt-daemon-system libvirt-clients bridge-utils virt-manager


   • qemu-kvm: Provides the core virtualization capabilities.
   • libvirt-daemon-system: Manages the VMs.
   • libvirt-clients: Provides command-line tools for managing VMs.
   • bridge-utils: Allows you to create network bridges for VMs.
   • virt-manager: A graphical tool for managing VMs (optional, but recommended).

4. After the installation is complete, verify that KVM is running:

   kvm-ok


   If KVM is properly installed, you should see a message indicating that your CPU supports KVM virtualization.

5. Add your user to the libvirt group to allow you to manage VMs without using sudo:

   sudo usermod -a -G libvirt $USER
   newgrp libvirt


   Log out and log back in for the group changes to take effect.

Step 2: Configure Networking

Networking is a crucial aspect of running VMs. You'll need to configure a network bridge to allow your VMs to communicate with each other and the outside world. Here's how to set up a network bridge:

1. Edit the network configuration file:

   sudo nano /etc/netplan/01-network-manager-all.yaml


   Note: The filename might be different depending on your Ubuntu version and configuration. Look for a .yaml file in the /etc/netplan/ directory.

2. Modify the file to create a bridge. Here's an example configuration:

   network:
       version: 2
       renderer: networkd
       ethernets:
           ens3:
               dhcp4: no
       bridges:
           br0:
               interfaces: [ens3]
               dhcp4: yes
               parameters:
                   stp: false
                   forward-delay: 0


   • Replace ens3 with the name of your network interface. You can find the name using the ip addr command.
   • This configuration creates a bridge named br0 and assigns your network interface to it. The bridge will obtain an IP address automatically using DHCP.

3. Apply the network configuration:

   sudo netplan apply


4. Verify that the bridge is created and has an IP address:

   ip addr show br0


   You should see an IP address assigned to the br0 interface.

Step 3: Create a Virtual Machine

With KVM, QEMU, and networking configured, you're now ready to create your first VM. You can use either the command line or the virt-manager graphical tool. Here, we'll cover both methods.

Using Virt-Manager (GUI)

1. Launch virt-manager by typing virt-manager in the terminal or searching for it in the application menu.
2. Click the "Create a new virtual machine" button (the monitor icon with a plus sign).
3. Choose the installation method. You can install from an ISO image, a network location, or import an existing disk image. For this example, let's use an ISO image.
4. Browse to the location of your ISO image and select it. Virt-manager will attempt to detect the operating system. If it doesn't, you can manually specify it.
5. Allocate memory and CPU resources to the VM. Keep in mind the resources available on your server and the requirements of the guest operating system.
6. Create a virtual disk for the VM. You can choose to create a new disk image or use an existing one.
7. Review the settings and click "Finish" to create the VM.
8. Virt-manager will start the VM, and you can proceed with the operating system installation.

Using the Command Line

1. Download an ISO image of the operating system you want to install on the VM. For example, you can download the Ubuntu Server ISO image.

2. Create a virtual disk image for the VM:

   qemu-img create -f qcow2 /var/lib/libvirt/images/myvm.qcow2 20G


   • -f qcow2: Specifies the disk image format (QCOW2 is recommended).
   • /var/lib/libvirt/images/myvm.qcow2: The path to the disk image file.
   • 20G: The size of the disk image (20 GB in this example).

3. Create the VM using the virt-install command:

   sudo virt-install \
   --name=myvm \
   --memory=2048 \
   --vcpus=2 \
   --os-variant=ubuntu20.04 \
   --disk path=/var/lib/libvirt/images/myvm.qcow2,size=20 \
   --cdrom=/path/to/ubuntu-20.04-live-server-amd64.iso \
   --network bridge=br0,model=virtio \
   --graphics none \
   --console pty,target_type=serial


   • --name: The name of the VM.
   • --memory: The amount of RAM to allocate to the VM (in MB).
   • --vcpus: The number of virtual CPUs to allocate to the VM.
   • --os-variant: The operating system variant (e.g., ubuntu20.04).
   • --disk path: The path to the virtual disk image.
   • --cdrom: The path to the ISO image.
   • --network bridge: The network bridge to use for the VM.
   • --graphics none: Disables graphical output (use this for server VMs).
   • --console: Configures the console for the VM.

4. After running the command, the VM will start, and you can connect to the console to complete the operating system installation. You can use the virsh console command:

   sudo virsh console myvm


Step 4: Manage Virtual Machines

Once your VMs are up and running, you'll need to manage them. Here are some common tasks and commands for managing VMs:

• Start a VM:

  sudo virsh start myvm


• Stop a VM:

  sudo virsh shutdown myvm


• Forcefully stop a VM:

  sudo virsh destroy myvm


• List running VMs:

  sudo virsh list


• List all VMs (including stopped ones):

  sudo virsh list --all


• Get VM information:

  sudo virsh dominfo myvm


Step 5: Optimizing VM Performance

To ensure your VMs run smoothly, consider these optimization tips:

• Use VirtIO drivers: VirtIO drivers are paravirtualized drivers that provide better performance than emulated drivers. Make sure to install VirtIO drivers in your guest operating systems.

• Allocate sufficient resources: Ensure your VMs have enough RAM, CPU, and storage to meet their needs. Monitor resource usage and adjust as necessary.

• Use SSD storage: Using solid-state drives (SSDs) can significantly improve VM performance, especially for disk-intensive workloads.

• Enable KSM (Kernel Samepage Merging): KSM allows the kernel to share identical memory pages between VMs, reducing memory usage and improving performance. To enable KSM, run:

  sudo systemctl enable ksmd
  sudo systemctl start ksmd


• Monitor VM performance: Use tools like top, htop, and iotop to monitor VM resource usage and identify performance bottlenecks.

Conclusion

Running virtual machines on an Ubuntu server offers numerous benefits, from resource optimization to enhanced security and flexibility. By following this guide, you can set up and manage VMs on your Ubuntu server with ease. Whether you're using the command line or the virt-manager graphical tool, you'll be able to create, manage, and optimize VMs to meet your specific needs. So go ahead, give it a try, and unlock the power of virtualization on your Ubuntu server! Remember resource optimization is key, and with KVM (Kernel-based Virtual Machine), you're well on your way to a more efficient server environment. By using VMs, you can significantly enhance your flexibility and scalability, making your Ubuntu server a powerhouse of productivity.
